Section VII-B-07: Mass Comparison of Projectiles Fired at 1.14 Joules

For this section, the listed and actual muzzle velocities can be compared by using the chart below:

Energy0.20g 0.25g0.30g 0.34g0.36g 0.43g0.45g 0.88g
1.14 J350 fps 313286 268261 239233 167
