ATP - 2.32 Joules

Section VII-B-10: Mass Comparison of Projectiles Fired at 2.32 Joules

For this section, the listed and actual muzzle velocities can be compared by using the chart below:

Energy	0.20g	0.25g	0.30g	0.34g	0.36g	0.43g	0.45g	0.88g
2.32 J	500 fps	447	408	383	373	341	333	238
