Section VII-B-14: Mass Comparison of Projectiles Fired at 4.55 Joules

For this section, the listed and actual muzzle velocities can be compared by using the chart below:

Energy	0.20g	0.25g	0.30g	0.34g	0.36g	0.43g	0.45g	0.88g
4.55 J	700 fps	626	572	537	522	477	467	334
