Section VII-B-03: Mass Comparison of Projectiles Fired at 0.58 Joules

For this section, the listed and actual muzzle velocities can be compared by using the chart below:

Energy0.20g 0.25g0.30g 0.34g0.36g 0.43g0.45g 0.88g
0.58 J250 fps 224204 192186 170167 119
