Section VII-B-09: Mass Comparison of Projectiles Fired at 1.88 Joules

For this section, the listed and actual muzzle velocities can be compared by using the chart below:

Energy0.20g 0.25g0.30g 0.34g0.36g 0.43g0.45g 0.88g
1.88 J450 fps 403367 345335 307300 215
